NEWS

Misawa,1 Apri1 2017:Nikkohm Co Ltd announces distribution partnership with ES Components. https://www.escomponents.com/

Misawa 1 April 2017
Nikkohm Co. Ltd is pleased to partner with ES Components (Sterling, Massachusetts, USA). ES Components will have the distribution rights of all products exclusively in North America and other parts of the world. As Nikkohm continues to expand in North American market ES Components brings over thirty years of distribution experience that would be an essential part of Nikkohm’s success.
https://www.escomponents.com/

PRESS RELEASE

NIKKOHM INTRODUCES SOT227 PACKAGED 900W POWER RESISTOR FOR INDUSTRIAL APPLICATIONS

Misawa, Japan (1 March 2017) — To provide design engineers with highly reliable, small size 900W power resistors in SOT227 package that shows lowest available reactance in the market Nikkohm has introduced RPK900 series for inverter applications. These unique resistors use Nikkohm’s proprietary thin film process on aluminum nitride substrate and offer 900W rated power, 5kV insulation, low parallel capacitance of 13pF, low series inductance13nH. Such a low reactance provides up to 10MHz high frequency operation and 1μs pulse operation.

Read More

NIKKOHM INTRODUCES QUICK CONNECT 600A Current Shunt FOR BATTERY CONTROL APPLICATIONS

Misawa, Japan (20 September 2017) — Nikkohm Co., Ltd. announced the release of a new and enhanced bus bar shunt of blade terminal in RCS 85184x series. This is a new Bus-Bar Battery Shunt resistor that has 36W power capability in the 85mm x 18mm x 4mm size with 50μΩ, 100μΩ and 125μΩ. In other words, it is possible to output 60 mV from the voltage terminal with a current of 600 A.

Read More

NIKKOHM INTRODUCES 600A Current Shunt FOR BATTERY CONTROL APPLICATIONS

Misawa, Japan (1 September 2017) — Nikkohm Co., Ltd. announced a new Bus-Bar Battery Shunt resistor that operates at 36W power capability in the 85mm x 18mm x 4mm size with 50μΩ, 100μΩ, 125μΩ. In other words, it is possible to output 60 mV from the voltage terminal with a current of 600 A.

Read More

NIKKOHM INTRODUCES 100W TO247 POWER RESISTOR FOR AUTOMOTIVE APPLICATIONSS

Misawa, Japan (1 August 2017) ---- To provide design engineers with higher performance, low ohms power resistors that operate up to 140A current with heavy terminals, lowest temperature rise and wider frequency range in the field Nikkohm has introduced RNP-100U series for inverter especially for automotive & motor control applications.

Read More

NIKKOHM INTRODUCES 800W POWER RESISTOR FOR INVERTER APPLICATIONS

Misawa, Japan (1 August 2017) — To provide design engineers with highly reliable, power resistors that operate with lowest temperature rise in the market Nikkohm has introduced RPU800 series for inverter applications. These unique high power resistors use Nikkohm’s proprietary thick film technology and thin film process on alumina substrate and offer 10kV insulation, low series inductance. “These are highly reliable resistors suitable for power electronics such as snubber resistor of thyristor inverter in the induction heating power equipments” said Shigeru Hidaka, CTO of Nikkohm. “The thermal resistance indicating the heat dissipation is only 0.8 °C/W which is exceptionally suitable for the liquid cooling system.”

Read More

NIKKOHM INTRODUCES 300W HIGH POWER FILM RESISTOR FOR AUTOMOTIVE APPLICATIONS

Misawa, Japan (1 March 2017) — To provide design engineers with lower profile highly reliable high power resistors that operate with lowest temperature rise in the market Nikkohm has introduced RPL320F series for automotive applications. “Compared to our SOT227 power resistors these offer 50% reduction in height at 5.5 mm and 30% reduction in weight” said Shigeru Hidaka, CTO of Nikkohm. “The heat rise is only 0.23 °C/W making these resistors most suitable for inverter applications. The wide resistance values of 100 mΩ to 1MΩ make Nikkohm’s RPL320F ideal for applications in bleeder resistor of motor speed control inverter, output filter of the motor inverter, bleeder resistor of the UPS, inrush current protection of DC-DC converter, dumping resistor of the crossover LC filter of the loudspeaker system in professional audio, snubber resistor of the inverter, filter resistor of the on board battery

Read More

NIKKOHM INTRODUCES 50W D2PAK/TO220 POWER RESISTOR FOR AUTOMOTIVE APPLICATIONS

Misawa, Japan (1 March 2017) — To provide design engineers with highly reliable, power resistors that operate with lowest temperature rise in the market Nikkohm has introduced RNP-50E and RNP-50U series for automotive applications. These unique resistors use Nikkohm’s proprietary thick film technology and thin film process on alumina substrate and offer lightweight, small footprint high power reliable resistors. “These are the high reliability resistors suitable for power electronics such as automotive, trains, motor inverters and in intelligent power modules,” said Shigeru Hidaka, CTO of Nikkohm. “The thermal resistance indicating the heat dissipation is only 2.3 °C/W which is exceptionally suitable for the printed circuit boards.”

Read More

PRODUCT

800W POWER RESISTOR FOR INVERTER APPLICATIONS

100W TO247 POWER RESISTOR FOR AUTOMOTIVE APPLICATIONS

300W HIGH POWER FILM RESISTOR FOR AUTOMOTIVE APPLICATIONS

50W D2PAK/TO220 POWER RESISTOR FOR AUTOMOTIVE APPLICATIONS
